One of the Quad Air's key strengths is its low battery consumption, which allows for up to 150 dives on a single user-replaceable commercial battery (for battery replacement, please contact your local Mares dealer. Refer to the Mares Locator). Additionally, the Quad Air can integrate tank data for up to three transmitters (sold separately), providing quick and intuitive communication to the diver and their companions. The transmitters use radiofrequency and feature a color-coded LED that changes from green (above 180 bar) to yellow (100 bar) to red (50 bar) to indicate the tank pressure level.
The Quad Air features mirrored buttons on the dial, which makes it easy to operate regardless of which arm it is worn on. It also includes a 'Runaway Deco Alarm' that alerts the diver when staying at the current depth will result in a significant increase in mandatory decompression stops, and a 'Deco Dive Planner' that adapts the surface interval input to the diver's needs.
Another great feature of the Quad Air is the multi-blend function, which allows for the tuning of three different probes and mixtures in a single dive without looking at the gauge, providing a high level of customization for divers.
The Quad Air is capable of downloading logbook data, and receiving firmware updates. Through the use of the Mares Dive Organizer Program (PC) and in conjunction with the Dive Link 2 USB interface clip and cable, data can be transferred between the Quad Air and the Dive Organizer Program.
Alternatively, the Mares Bluelink Pro uses low energy Bluetooth technology to communicate directly with the Mares App, or the MySSI App to download logbook data and firmware updates on your smart devices (Bluelink Pro cannot be used with PC/MAC to transfer data).
*Dive Link 2 and Bluelink Pro accessories sold separately.
The main features of the Quad Air dive computer are:
• Large and clear data display
• Hoseless tank data integration for up to three transmitters
• The "Runaway Deco Alarm" which alerts the user when staying at the current depth will cause a significant increase in mandatory deco stages
• The "Deco Dive Planner" with surface interval input that is adaptable to the user's needs
• Three-sector layout includes all the relevant data
• Two customizable fields for auxiliary information
• Four buttons for an intuitive user interface
• Mirror function of buttons while diving
• Multi-gas capable
• Battery: CR2450
Facts:
MATERIAL:CR2450
BATTERY DURATION:150 dives
NITROX USE:EAN from 21% to 99%
MAX DISPLAYED DEPTH:150m / 492ft
ASCENT RATE INDICATOR (M/MIN - FT/MIN):true
MEMORY CAPACITY:> 100hr
PROFILE SAMPLING RATES:5s
DISPLAY: Segment Display
GAS SWITCHING: true
STOPWATCH: true
WATCH: false
DUAL TIME: false
DAILY ALARM: false
PLAN MODE: true
CHOICE_MET_IMP: true
FRESH AND SEAWATER SETTINGS: true
RESID_NITRO_RESET: true
OPTION TO EXCLUDE AUDIBLE ALARMS: true
EXCLUSION OF "UNCONTROLLED ASCENT ":true
ALTITUDE ADJUSTMENT: true
TEMPERATURE: Measurement range: -10 °C to +50 °C / 14 °F to 122 °FLOGBOOK MEMORY:100 hours of dive profile at 5-second sampling rate
DISPLAY MATERIAL: Mineral glass
CLOCK: Quartz clock, time, date, dive time display up to 99 minutes
UPGRADEABLE SOFTWARE: true
AIR INTEGRATED: true
GRAPHIC AND NUMERIC
TANK PRESSURE: false
USB CHARGER: false
